overview
Range consist of 59 customizable models.
On request the models can be equipped with non-standard: coils, defrosting and fan motors.
Range consist of 59 customizable models.
On request the models can be equipped with non-standard: coils, defrosting and fan motors.
Range consist of 59 customizable models.
On request the models can be equipped with non-standard: coils, defrosting and fan motors.
applications
- Blast freezing
- Blast chilling
- Blast freezing
- Blast chilling
- Blast freezing
- Blast chilling
capacity range
From 9,5 to 123 kW
From 9,5 to 114 kW
From 10,3 to 123 kW
Technical Information
Coil features
- The entire range is equipped with high efficiency coils made from special profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants.
- The entire range is equipped with high efficiency coils made from special profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants.
- The entire range is equipped with high efficiency coils made from special profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants.
Casing
- Made of a magnesium aluminum alloy, with a smooth finish covered by a plastic protection film.
Fan motors
The standard AC fan motors employed have the following features:
Ø 560 mm
- fan motor module: from 2 to 8
- external rotor
- three-phase 400V/3/50 Hz
- dual speed
- epoxy coated steel fan guard
Ø 630 mm
- fan motor module: from 2 to 6
- external rotor
- three-phase 400V/3/50-60 Hz
- dual speed
- epoxy coated steel fan guard
The standard AC fan motors employed have the following features:
Ø 560 mm
- fan motor module: from 2 to 8
- external rotor
- three-phase 400V/3/50 Hz
- dual speed
- epoxy coated steel fan guard
Ø 630 mm
- fan motor module: from 2 to 6
- external rotor
- three-phase 400V/3/50-60 Hz
- dual speed
- epoxy coated steel fan guard
The standard AC fan motors employed have the following features:
Ø 560 mm
- fan motor module: from 2 to 8
- external rotor
- three-phase 400V/3/50 Hz
- dual speed
- epoxy coated steel fan guard
Ø 630 mm
- fan motor module: from 2 to 6
- external rotor
- three-phase 400V/3/50-60 Hz
- dual speed
- epoxy coated steel fan guard
Defrost
Wiring
- The electric parts and casework are predisposed for grounding.
- The wiring of the heaters is carried out in separate IP 54 protection grade junction boxes.
Certifications
- CE
- PED
- SASO
Published data
- EN 328 reference standard.
- Nominal capacity assessed in practical operating ambient i.e. in wet conditions.
- EMEA: R448A refrigerant (mid point).
- APAC: R404A refrigerant.
- Air inlet temperature 0 °C.
- Evaporating temperature –8 °C.
- TD 8 K.
- EN 328 reference standard.
- Nominal capacity assessed in practical operating ambient i.e. in wet conditions.
- R448A refrigerant (mid point).
- Air inlet temperature 0 °C.
- Evaporating temperature –8 °C.
- TD 8 K.
- EN 328 reference standard.
- Nominal capacity assessed in practical operating ambient i.e. in wet conditions.
- R404A refrigerant.
- Air inlet temperature 0 °C.
- Evaporating temperature –8 °C.
- TD 8 K.
Downloads
Scelte Selection Software
SCELTE is a web based application to select all ECO™ branded coolers and to configure bespoke models.
The selection engine is faster than ever and will allow you to select the unit that suit your requirements, also thanks to a comprehensive database with all new generation refrigerants available on the market.
