Coils - For Coiltech® branded coolers

COILS selection software is all you need to make the right choice from Coiltech® branded product range.

Available products in the COILS Software

Transformer oil cooler ALFA, BETA & CETA

Specify required performance including any demands for noise limits.
The program will present a number of alternatives, which can be easily compared in regard to cooling capacity, liquid pressure drop, noise, and price.

Motor Generator Coolers (MGC)

The focus is laid on consideration of polluted environments. In case of pollution, a certain over dimensioning of the surface is often made in order to fulfill the cooling requirements. Alternatively, a fouling factor may be specified for the inner or outer surface of the coil. An optional choice is hydrogen gas as outer medium instead of air.

Heat Exchangers

Selection of coils for heating or cooling of air with water plus any freeze protection used, evaporation/condensation media, or steam.

Air unit heaters ATD & LVD

The program handles liquid coupled heat recovery systems with up to 20 input and exhaust coils. Input data to be specified is airflow, temperature, and humidity for each coil and required temperature efficiency, if any. It is also possible to specify required coil dimensions. The program presents the performance under the dimensioning conditions but also for three other surrounding temperatures. In case an anti-freeze control is needed, the performance of the system under the adjusted conditions will be presented as well. If required, the program will also present a system chart. This system chart suggests dimensioning of the system, including required tube dimensions, pump, vents, and control devices. Finally, the program offers a tool for estimating the profitability – considering location, operating time, investment costs, energy price, etc.

Enter your contact details to download COILS

IMPORTANT NOTES

Current versions: Coils1g 9.5.49.0 - Coils3g 2026.3.0.0
To get specific version please contact Modine Sales in Söderköping at orders-sodese@modine.com
For installation and software support please contact us at coilselection@modine.com
Customer specific, requires customer code
Customer specific version can include prices, but also customer defined designs

Application	Customer code
Motor Generator Coolers (MGC) & Trafo coolers	coils3g1497
Motor Generator Coolers (MGC)	coils3g1523
Trafo Coolers	coils3g1632

Can’t find your customer code in the list?
Please contact us at orders-sodese@modine.com to request a specific customer code or for any other questions.
