overview
Range consists of 9 customizable models: 6 for medium temperature and 3 for low temperature.
According to the cold room temperatures, the range is divided as follows:
- CVC E6, F6 and A6 are designed for medium cold room temperatures (≥ –15 °C), with 6 mm fin spacing;
- CVC G8, F8 and E8 are designed for low cold room temperatures (≥ –35 °C), with 8 mm fin spacing.
On request, the models can be equipped with non-standard: coils, defrosting, and fan motors.
Range consists of 9 customizable models: 6 for medium temperature and 3 for low temperature.
According to the cold room temperatures, the range is divided as follows:
- CVC E6, F6 and A6 are designed for medium cold room temperatures (≥ –15 °C), with 6 mm fin spacing;
- CVC G8, F8 and E8 are designed for low cold room temperatures (≥ –35 °C), with 8 mm fin spacing.
On request, the models can be equipped with non-standard: coils, defrosting, and fan motors.
applications
- Small cold rooms
- Commercial cold rooms
- Small cold rooms
- Commercial cold rooms
capacity range
From 2,4 to 7,4 kW
From 2,4 to 7,4 kW
Technical Information
Coil features
- This new range is equipped with highly efficient coils made from aluminum fins and special copper tubes.
- Design pressure: up to 80 bar.
- This new range is equipped with highly efficient coils made from aluminum fins and special copper tubes.
- Design pressure: up to 80 bar.
Casing
- Casing Features Made of a magnesium aluminum alloy, with a smooth finish covered by a plastic protection film.
Fan motors
The standard AC fan motors employed have the following features:
Ø 250 mm
- fan motor module: 2 or 3
- shaded pole single-phase 230V/1/50-60Hz
- fibreglass charged polyamide fan guard
Ø 315 mm
- fan motor module: 2 or 3
- external rotor single-phase 230V/1/50-60Hz
- built-in electric capacitor
- epoxy coated steel fan guard
Ø 350 mm
- fan motor module: 2 or 3
- external rotor single-phase 230V/1/50-60Hz
- built-in electric capacitor
- epoxy coated steel fan guard
The optional high efficiency EC fan motors have the following features:
Ø 250 mm
- fan motor module: 2 or 3
- single-phase 230V/1/50-60Hz
- fibreglass charged polyamide fan guard
Ø 315 mm
- fan motor module: 2 or 3
- external rotor single-phase 230V/1/50-60Hz
- epoxy coated steel fan guard
Ø 350 mm
- fan motor module: 2 or 3
- external rotor single-phase 230V/1/50-60Hz
- epoxy coated steel fan guard
The standard AC fan motors employed have the following features:
Ø 250 mm
- fan motor module: 2 or 3
- shaded pole single-phase 230V/1/50-60Hz
- fibreglass charged polyamide fan guard
Ø 315 mm
- fan motor module: 2 or 3
- external rotor single-phase 230V/1/50-60Hz
- built-in electric capacitor
- epoxy coated steel fan guard
Ø 350 mm
- fan motor module: 2 or 3
- external rotor single-phase 230V/1/50-60Hz
- built-in electric capacitor
- epoxy coated steel fan guard
The optional high efficiency EC fan motors have the following features:
Ø 250 mm
- fan motor module: 2 or 3
- single-phase 230V/1/50-60Hz
- fibreglass charged polyamide fan guard
Ø 315 mm
- fan motor module: 2 or 3
- external rotor single-phase 230V/1/50-60Hz
- epoxy coated steel fan guard
Ø 350 mm
- fan motor module: 2 or 3
- external rotor single-phase 230V/1/50-60Hz
- epoxy coated steel fan guard
Defrost
Wiring
- The electric parts and casing are connected to an earth terminal.
- The wiring of motors and heaters is carried out in separate IP 54 protection grade junction boxes.
Certifications
- CE
- PED
Published data
- Nominal capacity assessed in practical operating ambient, i.e. in wet conditions, in direct expansion application, CO2 refrigerant; air inlet temperature 0 °C, evaporating temperature –7 °C; TD 7K.
- Nominal capacity assessed in practical operating ambient, i.e. in wet conditions, in direct expansion application CO2 refrigerant; air inlet temperature 0 °C; evaporating temperature –7 °C; TD 7 K.
