overview
Range consists of 11 customizable models.
The models have been designed for canalized installation with maximum available static pressure 300 Pa.
On request, the models can be equipped with non-standard coils and fan motors.
Range consists of 11 customizable models.
The models have been designed for canalized installation with maximum available static pressure 300 Pa.
On request, the models can be equipped with non-standard coils and fan motors.
applications
- Air conditioning
- Refrigeration systems
- Air conditioning
- Refrigeration systems
capacity range
From 22,3 to 413 kW
From 22,3 to 413 kW
Technical Information
Coil features
- The entire range is equipped with high efficiency coils made from special “Air Intake” profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants.
- They are supplied charged with dry air at 2 bars and 2,1 mm fin spacing for the entire range.
- The entire range is equipped with high efficiency coils made from special “Air Intake” profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants.
- They are supplied charged with dry air at 2 bars and 2,1 mm fin spacing for the entire range.
Casing
- Made of a pre-painted galvanised metal sheet, with a smooth finish covered by a plastic protection film.
- The models have a special compartment designed to accommodate the compressor (not supplied) with a reinforced base and support platform, hinged doors, removable panels and inner protected compartment for the positioning of possible electrical switchboards.
Fan motors
The standard AC fan motors employed have the following features:
Ø 450 mm
- fan motor module: 1 or 2
- 230V/1/50-60 Hz single-phase
- with 4 or 6 poles
- external rotor type
- built-in electric capacitor
- epoxy coated steel fan guard
Ø 500 mm
- fan motor module: 1 or 2
- 230V/1/50-60 Hz single-phase
- with 4 or 6 poles
- external rotor type
- built-in electric capacitor
- epoxy coated steel fan guard
Ø 630mm
- fan motor module: 1 or 2
- 230V/1/50 Hz 6 poles single-phase or 400V/3/50 Hz 8 poles three-phase
- external rotor type
- built-in electric capacitor
- epoxy coated steel fan guard
Ø 710mm
- fan motor module: 1 or 2
- 230V/1/50 Hz 6 poles single-phase or 400V/3/50 Hz 4 poles three-phase
- external rotor type
- built-in electric capacitor
- epoxy coated steel fan guard
The optional high efficiency EC fan motors have the following features:
Ø 450, 500, 630 or 710 mm
- speed regulator with 0-10V signal
- fan motor module: the same as AC fan motors
- operating temperature: –25 °C ÷ +60 °C
The standard AC fan motors employed have the following features:
Ø 450 mm
- fan motor module: 1 or 2
- 230V/1/50-60 Hz single-phase
- with 4 or 6 poles
- external rotor type
- built-in electric capacitor
- epoxy coated steel fan guard
Ø 500 mm
- fan motor module: 1 or 2
- 230V/1/50-60 Hz single-phase
- with 4 or 6 poles
- external rotor type
- built-in electric capacitor
- epoxy coated steel fan guard
Ø 630mm
- fan motor module: 1 or 2
- 230V/1/50 Hz 6 poles single-phase or 400V/3/50 Hz 8 poles three-phase
- external rotor type
- built-in electric capacitor
- epoxy coated steel fan guard
Ø 710mm
- fan motor module: 1 or 2
- 230V/1/50 Hz 6 poles single-phase or 400V/3/50 Hz 4 poles three-phase
- external rotor type
- built-in electric capacitor
- epoxy coated steel fan guard
The optional high efficiency EC fan motors have the following features:
Ø 450, 500, 630 or 710 mm
- speed regulator with 0-10V signal
- fan motor module: the same as AC fan motors
- operating temperature: –25 °C ÷ +60 °C
Wiring
- The fan motors and the casework are predisposed for grounding.
Certifications
- CE
- PED
Published data
- EN 327 reference standard.
- The stated capacity is assessed based on ambient temperature 25 °C and condensing temperature 40 °C with R448A (mid-point).
- EN 327 reference standard.
- The stated capacity is assessed based on ambient temperature 25 °C and condensing temperature 40 °C with R448A (mid-point).
