overview
The condensers of the LCE range are particularly suitable for installation in small condensing units.
Range consists of 16 customizable models.
On request the models can be equipped with non-standard coils.
The condensers of the LCE range are particularly suitable for installation in small condensing units.
Range consists of 16 customizable models.
On request the models can be equipped with non-standard coils.
applications
- Small Condensing units
- Small Condensing units
capacity range
From 0,37 to 2,4 kW
From 0,37 to 2,4 kW
Technical Information
Coil features
- The entire range is equipped with high efficiency coils made from special profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants. For the entire range 3 mm fin spacing.
- The entire range is equipped with high efficiency coils made from special profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants. For the entire range 3 mm fin spacing.
Casing
- Made of a galvanized steel.
Fan motors
The standard AC fan motors employed have the following features:
Ø 172, 200, 230, 254, 300 mm
- single-phase 230V/1/50 Hz shaded pole
The standard AC fan motors employed have the following features:
Ø 172, 200, 230, 254, 300 mm
- single-phase 230V/1/50 Hz shaded pole
Certifications
- CE
- PED
Published data
- EN 327 reference standard.
- The stated capacity is assessed based on ambient temperature 25 °C and condensing temperature 40 °C with R448A (mid-point).
- EN 327 reference standard.
- The stated capacity is assessed based on ambient temperature 25 °C and condensing temperature 40 °C with R448A (mid-point).
Downloads
Scelte Selection Software
SCELTE is a web based application to select all ECO™ branded coolers and to configure bespoke models.
The selection engine is faster than ever and will allow you to select the unit that suit your requirements, also thanks to a comprehensive database with all new generation refrigerants available on the market.
