overview
Range consist of 8 customizable models.
On request the models can be equipped with non-standard: coils, defrosting and fan motors.
Range consist of 8 customizable models.
On request the models can be equipped with non-standard: coils, defrosting and fan motors.
Range consist of 8 customizable models.
On request the models can be equipped with non-standard: coils, defrosting and fan motors.
applications
- Reach-in cabinets
- Small cold rooms
- Walk-in cabinets
- Low ceiling commercial refrigeration cold rooms
- Food processing rooms (fresh and sensitive products, sea food, meat)
- Reach-in cabinets
- Small cold rooms
- Walk-in cabinets
- Low ceiling commercial refrigeration cold rooms
- Food processing rooms (fresh and sensitive products, sea food, meat)
- Reach-in cabinets
- Small cold rooms
- Walk-in cabinets
- Low ceiling commercial refrigeration cold rooms
- Food processing rooms (fresh and sensitive products, sea food, meat)
capacity range
From 0,55 to 3,98 kW
From 0,55 to 3,98 kW
From 0,55 to 3,98 kW
Technical Information
Coil features
- The entire range is equipped with high efficiency coils made from special profile aluminium fins and inner grooved copper tube.
- Thanks to the new geometry the coils are suitable for new generation refrigerants. With 4,5/9mm dual fin spacing for the entire range (for room temperatures ≥ –25 °C).
- The updated coil design responds to the recent guidelines governing the reduction of HFC gases with high greenhouse effect.
- The entire range is equipped with high efficiency coils made from special profile aluminium fins and inner grooved copper tube.
- Thanks to the new geometry the coils are suitable for new generation refrigerants. With 4,5/9mm dual fin spacing for the entire range (for room temperatures ≥ –25 °C).
- The updated coil design responds to the recent guidelines governing the reduction of HFC gases with high greenhouse effect.
- The entire range is equipped with high efficiency coils made from special profile aluminium fins and inner grooved copper tube.
- Thanks to the new geometry the coils are suitable for new generation refrigerants. With 4,5/9mm dual fin spacing for the entire range (for room temperatures ≥ –25 °C).
- The updated coil design responds to the recent guidelines governing the reduction of HFC gases with high greenhouse effect.
Casing
- Made of a magnesium aluminum alloy, with a smooth finish covered by a plastic protection film.
Fan motors
The standard AC fan motors employed have the following features:
Ø 230 mm
- fan motor module: from 1 to 5
- single-phase 230V/1/50-60 Hz
- fibreglass charged polyamide fan guard
The optional high efficiency EC fan motors have the following features:
Ø 230 mm
- fan motor module: from 1 to 5
- single-phase 230V/1/50-60Hz
- fibreglass charged polyamide fan guard
The standard AC fan motors employed have the following features:
Ø 230 mm
- fan motor module: from 1 to 5
- single-phase 230V/1/50-60 Hz
- fibreglass charged polyamide fan guard
The optional high efficiency EC fan motors have the following features:
Ø 230 mm
- fan motor module: from 1 to 5
- single-phase 230V/1/50-60Hz
- fibreglass charged polyamide fan guard
The standard AC fan motors employed have the following features:
Ø 230 mm
- fan motor module: from 1 to 5
- single-phase 230V/1/50-60 Hz
- fibreglass charged polyamide fan guard
The optional high efficiency EC fan motors have the following features:
Ø 230 mm
- fan motor module: from 1 to 5
- single-phase 230V/1/50-60Hz
- fibreglass charged polyamide fan guard
Defrost
Wiring
- The electric parts and casing are connected to a earth terminal. The wiring of the motors and heaters is carried out in separate IP 54 protection grade junction boxes.
Certifications
- CE
- PED
Published data
- EN 328 reference standard.
- Nominal capacity assessed in practical operating ambient i.e. in wet conditions.
- EMEA: R448A refrigerant (mid point).
- APAC: R404A refrigerant.
- Air inlet temperature 0 °C.
- Evaporating temperature –8 °C.
- TD 8 K.
- EN 328 reference standard.
- Nominal capacity assessed in practical operating ambient i.e. in wet conditions.
- R448A refrigerant (mid point).
- Air inlet temperature 0 °C.
- Evaporating temperature –8 °C.
- TD 8 K.
- EN 328 reference standard.
- Nominal capacity assessed in practical operating ambient i.e. in wet conditions.
- R404A refrigerant.
- Air inlet temperature 0 °C.
- Evaporating temperature –8 °C.
- TD 8 K.
