overview
Range consist of 5 customizable models.
For room temperatures down to –5 °C the electric defrost version is advisable, whereas for lower temperatures (≥ –12 °C) an additional electric heater in the drip tray is recommended.
On request the models can be equipped with non-standard: coils, defrosting and fan motors.
Range consist of 5 customizable models.
For room temperatures down to –5 °C the electric defrost version is advisable, whereas for lower temperatures (≥ –12 °C) an additional electric heater in the drip tray is recommended.
On request the models can be equipped with non-standard: coils, defrosting and fan motors.
applications
- Reach-in cabinets
- Display cases
- Small cold rooms
- Reach-in cabinets
- Display cases
- Small cold rooms
capacity range
From 0,51 to 2,56 kW
From 0,51 to 2,56 kW
Technical Information
Coil features
- The entire EP range is equipped with high efficiency coils suitable for new generation refrigerants made from special profile aluminium fins and inner grooved copper tube.
- Dual fin spacing 3,5/7 mm.
- The updated coil design responds to the recent guidelines governing the reduction of HFC gases with high greenhouse effect.
- The entire EP range is equipped with high efficiency coils suitable for new generation refrigerants made from special profile aluminium fins and inner grooved copper tube.
- Dual fin spacing 3,5/7 mm.
- The updated coil design responds to the recent guidelines governing the reduction of HFC gases with high greenhouse effect.
Casing
- Made of a magnesium aluminum alloy, with a smooth finish covered by a plastic protection film.
Fan motors
The standard AC fan motors employed have the following features:
Ø 230 mm
- fan motor module: from 1 to 3
- single-phase 230V/1/50-60 Hz
- fibreglass charged polyamide fan guard
The optional high efficiency EC fan motors have the following features:
Ø 230 mm
- fan motor module: from 1 to 3
- single-phase 230V/1/50-60Hz
- fibreglass charged polyamide fan guard
The standard AC fan motors employed have the following features:
Ø 230 mm
- fan motor module: from 1 to 3
- single-phase 230V/1/50-60 Hz
- fibreglass charged polyamide fan guard
The optional high efficiency EC fan motors have the following features:
Ø 230 mm
- fan motor module: from 1 to 3
- single-phase 230V/1/50-60Hz
- fibreglass charged polyamide fan guard
Defrost
Wiring
- The fan motors and the electric heaters of the EP/B models are prewired in IP 54 junction boxes.
Certifications
- CE
- PED
Published data
- EN 328 reference standard.
- Nominal capacity assessed in practical operating ambient i.e. in wet conditions.
- R448A refrigerant (media glide).
- air inlet temperature 0 °C).
- evaporating temperature –8 °C.
- TD 8 K.
- EN 328 reference standard.
- Nominal capacity assessed in practical operating ambient i.e. in wet conditions.
- R448A refrigerant (media glide).
- air inlet temperature 0 °C).
- evaporating temperature –8 °C.
- TD 8 K.
Downloads
Scelte Selection Software
SCELTE is a web based application to select all ECO™ branded coolers and to configure bespoke models.
The selection engine is faster than ever and will allow you to select the unit that suit your requirements, also thanks to a comprehensive database with all new generation refrigerants available on the market.
