overview
Range consist of 34 customizable models.
On request the models can be equipped with non-standard coils and fan motors.
Range consist of 34 customizable models.
On request the models can be equipped with non-standard coils and fan motors.
applications
- Air conditioning
- Refrigeration systems
- Air conditioning
- Refrigeration systems
capacity range
From 40,8 to 260 kW
From 40,8 to 260 kW
Technical Information
Coil features
- The entire range is equipped with high efficiency coils made from special “Air Intake” profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants.
- They are supplied charged with dry air at 2 bars and 2,1 mm fin spacing for the entire range.
- The entire range is equipped with high efficiency coils made from special “Air Intake” profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants.
- They are supplied charged with dry air at 2 bars and 2,1 mm fin spacing for the entire range.
Casing
- Made of a pre-painted galvanised metal sheet, with a smooth finish covered by a plastic protection film.
- All models are equipped with a special soundproof compartment to accommodate the compressor (not supplied). Given the particular structure of this space quiet operation is ensured.
Fan motors
The standard AC fan motors employed have the following features:
Ø 630 mm
- fan motor module: from 3 to 5
- External rotor type
- 400V/3/50-60 Hz three-phase
- epoxy coated steel fan guard
- 4 - 6 - 8 - 12 poles;
The optional high efficiency EC fan motors have the following features:
Ø 630 mm
- fan motor module: from 3 to 5
- speed control with 0-10V signal
- additional speed regulator with MODBUS system
- operating temperature: –25 ÷ +60 °C
The standard AC fan motors employed have the following features:
Ø 630 mm
- fan motor module: from 3 to 5
- External rotor type
- 400V/3/50-60 Hz three-phase
- epoxy coated steel fan guard
- 4 - 6 - 8 - 12 poles;
The optional high efficiency EC fan motors have the following features:
Ø 630 mm
- fan motor module: from 3 to 5
- speed control with 0-10V signal
- additional speed regulator with MODBUS system
- operating temperature: –25 ÷ +60 °C
Wiring
- The fan motors and the casework are predisposed for grounding.
Certifications
- CE
- PED
Published data
- EN 327 reference standard.
- The stated capacity is assessed based on ambient temperature 25 °C and condensing temperature 40 °C with R448A (mid-point).
- EN 327 reference standard.
- The stated capacity is assessed based on ambient temperature 25 °C and condensing temperature 40 °C with R448A (mid-point).
